lesson 02

Language Basics

This lesson is a reference. Look at the important sections, but you do not need to memorize everything here before building something. Come back when you encounter a feature you have not seen before.

Bindings

There are four binding forms:

let — immutable name; cannot be reassigned
var — mutable local value
mesh — visible scene state; creates a leader/follower pair (covered in depth in the Animation lesson)
param — presenter-controlled value; exposed as a slider in presentation mode (advanced / niche)

let radius = 0.45
var count = 0
mesh dot = fill{CYAN} Circle(radius)
param speed = 1.0

Dynamic Typing

Monocurl is dynamically typed. A variable can hold any value and can be reassigned to a different type.

var x = 7
x = "hello"
x = [1, 2, 3]
print x

Use print while authoring to inspect values. Print output appears inline in the editor and in the console (alternate to timeline).

Deep Copy

Assignment always performs a deep copy.

var a = [[1, 2], [3, 4]]
var b = a
b[0][0] = 99
print [a, b]
# a is unchanged; b[0][0] is 99

Direction Literals

Monocurl has compact vector literals for common directions, which are often used for positioning.

let p = 1.5r + 0.8u       # [1.5, 0.8, 0]
let q = 2l + 1d           # [-2, -1, 0]
let behind = 3b           # [0, 0, 3]

l / r — left / right (negative / positive x)
u / d — up / down (positive / negative y)
b / f — backward / forward (positive / negative z)

Direction literals are just three-element lists. You can pass them to shift{} or center{}, and use them anywhere a vector is expected.

Lists And Maps

Lists use zero-based indexing. Maps use key -> value pairs.

var pts = []
pts .= 1l
pts .= 1u
pts = pts .. 1r      # .. appends; .= is shorthand for x = x .. y

let labels = ["origin" -> ORIGIN, "right" -> 1r, "up" -> 1u]
print [pts, labels["origin"]]

Block Syntax

block {} is a multi-line expression that accumulates a list. Lines beginning with . append to an implicit return value; the whole block evaluates to that list.

let row = block {
    for (i in range(0, 4)) {
        . center{[i - 1.5, 0, 0]} fill{CYAN} Square(0.4)
    }
    . center{2r} color{ORANGE} Text("end", 0.55)
}

Lambdas And Labeled Arguments

Functions are lambdas, which are treated first class. Arguments can have defaults, and a braced body can use return.

let square = |x| x * x
let capture = 3
let weighted = |x, weight = 1| x * weight + capture
let hyp = |a, b| {
    return sqrt(a * a + b * b)
}

video01-language.mcl

let Ball = |pos, radius, col|
    center{pos} fill{alpha{0.2} col} stroke{col, 2} Circle(radius)

mesh ball = Ball(pos: 1.4l, radius: 0.35, col: BLUE)

slide "move"
    # Mutate individual fields; the Ball(...) call is recomputed from them
    ball.pos = 1.4r
    ball.radius = 0.6
    ball.col = ORANGE
    play Lerp(1.5)

This is not object mutation in the usual sense. ball.pos = 1.4r edits the labeled argument stored inside the live Ball(...) invocation, then the entire call re-runs with the new argument. This is how Lerp knows how to smoothly interpolate between the two states: it interpolates each argument independently and reconstructs the mesh at each frame.

Operators

mesh shape =
    center{pos: 1r}       # positions the result
    fill{alpha{0.18} BLUE} stroke{BLUE, 2}
    Circle(radius: 0.5)      # base constructor

# you can access inner attributes
shape.radius = 1.0
# or attributes of the operators
shape.pos = 1l

Read right to left: Circle(0.5) creates the geometry; stroke, fill, and center transform it in sequence. You can define your own operators with operator in terms of existing ones:

let soft_style = operator |target, col|
    fill{alpha{0.2} col}
    stroke{col, 2}
    target

mesh shapes = [
    center{1.3l} soft_style{BLUE} Circle(0.45),
    center{1.3r} soft_style{ORANGE} Square(0.75)
]

Built-in operators handle styling (fill, stroke, color, alpha), positioning (center, shift, rotate, scale), layout (next_to, to_side), and identity (tag).

Operators also carry animation semantics, which will be discussed later.

Control Flow

Standard control flow: if/else if/else, for, while, break, continue. Use them to build data before turning it into meshes.

var above = []
let values = [0.75, 1.35, 0.92, 1.52, 1.05]
for (v in values) {
    if (v > 1.1) {
        above .= v
    }
}
print above

# range(start, stop) or range(start, stop, step)
for (i in range(0, 5)) {
    print i
}

Recursive lambdas take themselves as an explicit self argument. This is standard in lambda calculus, but it may look strange if you haven't seen it before.

let fib = |self, n| {
    if (n <= 1) { return n }
    return self(self, n - 1) + self(self, n - 2)
}
print fib(fib, 8)

Putting It Together

A typical helper function builds a labeled mesh and uses operators for styling. The labeled arguments become animation keyframe fields.

rendered monocurl scene — image01-language.mcl
